STEEL BAR MACHINERY

8 ITEMS

Hide Filter

Price

 150,000.00

Quantity

- +

Total

 150,000.00

0 reviews

Information

Add to cart

Compare

TECHNICAL SPECIFICATIONS

Capacity: 40mm
Power (kW): 4
Thread Pitch: 3mm
Drive Type : Geared
Material: EN8
Electric Supply: 415V 3phase 50Hz
Patten: Parrallel.
Rpm:1440
No. of pole : 4
No. of capstna: 4

KEY FEATURES:

Automatic Control Panel with PLC controller for easy production or process.
Straightening Rollers give accurate straightness without damaging rebars.
Digital measurement system for correct lengths.
Easy to operate, Low maintenance and cost effective.

Price

 2,200,000.00

Quantity

- +

Total

 2,200,000.00

0 reviews

Information

Add to cart

Compare

SPECIFICATIONS:

Automatic Stirrup Bender Machine
Capacity Single Wire: 5 - 13 (MM) Dia.
Capacity Double Wire: 5 - 10 (MM) Dia.
Production Capacity: 250-280 tons per Month
Max. Bending Angle:±180° [Double Direction].
Max. Bending Speed:1100 [°/sec]
Max. Bending Speed:1100 [°/sec]
Mandrel Diameter: Φ25 – Φ30 [mm]
Max. Length of the Stirrup Side:2300 [mm].
Min. Length of the Stirrup Side:120mm.
Length Tolerance: ± 1 [mm]
Bending Tolerance: ± 1°
Average air-compressed consumption: 6[I/mm]
Average Electric Power Consumption: 5 kW/h.
Traction Motor : 7.5 kw
Bending Motor : 1.8 kw
Cutting Motor : 2.2 kw
Feeding Motor : 1.5 kw
Air Consumption : 2 kw
Electric Supply: 415V 3 phase 50Hz.
Overall Machine Weight: 3300 Kg (Approx).
Overall Dimension: 3530 × 1030 × 2110
[mm]

KEY FEATURES:

Can Edit any 2D Shapes with Max. 50 Angles, the data base can store more than 500 shapes.
Different shapes can be processed continuously without stop, furthermore no need to stop the processing while adjusting the bending angle.
Large Storage Capacity can save 500 Processing Geometric Designs, High Degree Automation.
High power feeding Servo Motor's To Ensure Straightening, Bending & Cutting Accuracy.

Price

 160,000.00

Quantity

- +

Total

 160,000.00

0 reviews

Information

Add to cart

Compare

TECHNICAL SPECIFICATIONS

"Heavy Duty Bar Cutting Machine
Power : 5Hp
II Grade Rebar Steel(TMT) :36mm Max (Fe500D/Fe550D)
Electrical Supply : 415V,50Hz, 3Ph
Motor Speed :2880Rpm
Working Rpm : 32 Rpm
Stroke Per Min: 60
Size Approx:1200 X 480 X 740 (MM)

KEY FEATURES:

Safety Cover For Operators Safety.
Oil Bathed Gear Box that reduces wear and tear of Gear And Pinion.
Special Alloy Steel Cutting Blades Which are Given Proper Heat Treatment For Longer Cutting Life.
Cutting Through Pedal Switch If Required.
Interchangeable Cutting Blades with Eight Cutting Edges.
Smooth Cutting Sections."

Price

 140,000.00

Quantity

- +

Total

 140,000.00

0 reviews

Information

Add to cart

Compare

TECHNICAL SPECIFICATIONS

"Heavy Duty Bar Cutting Machine
Power : 5Hp
II Grade Rebar Steel(TMT) :32mm Max (fe500/Fe500D)
Electrical Supply : 415V,50Hz, 3Ph
Motor Speed :2880Rpm
Working Rpm : 32 Rpm
Stroke Per Min: 60
Size Approx:1200 X 480 X 740 (MM)

KEY FEATURES:

Safety Cover For Operators Safety.
Oil Bathed Gear Box that reduces wear and tear of Gear And Pinion.
Special Alloy Steel Cutting Blades Which are Given Proper Heat Treatment For Longer Cutting Life.
Cutting Through Pedal Switch If Required.
Interchangeable Cutting Blades with Eight Cutting Edges.
Smooth Cutting Sections."

SKU:
8461

Price

 30,000.00

Quantity

- +

Total

 30,000.00

0 reviews

Information

Add to cart

Compare

TECHNICAL SPECIFICATIONS

Max. Steel Dia: 16 / 22 / 25 mm
Tmt Steel Bar Dia : 12 / 16 / 20 mm
Motor : 1.5 / 1300 Watt 220V / 1300 Watt 220V
Strokes /Min. : 30 / 4 / 4
Blade Thickness : 12mm / 11mm / 15mm
Weight : 80kg / 15kg / 25kg
Overall Size : 650x400x540 / 500x200x300 / 565x230x345

KEY FEATURES:

Dimensional accuracy
Sturdy contraction
Corrosion against resistance.
