AUTOMATIC STIRRUP BENDER MACHINE BMC-ASB

SPECIFICATIONS:

Automatic Stirrup Bender Machine
Capacity Single Wire: 5 – 13 (MM) Dia.
Capacity Double Wire: 5 – 10 (MM) Dia.
Production Capacity: 250-280 tons per Month
Max. Bending Angle:±180° [Double Direction].
Max. Bending Speed:1100 [°/sec]
Max. Bending Speed:1100 [°/sec]
Mandrel Diameter: Φ25 – Φ30 [mm]
Max. Length of the Stirrup Side:2300 [mm].
Min. Length of the Stirrup Side:120mm.
Length Tolerance: ± 1 [mm]
Bending Tolerance: ± 1°
Average air-compressed consumption: 6[I/mm]
Average Electric Power Consumption: 5 kW/h.
Traction Motor : 7.5 kw
Bending Motor : 1.8 kw
Cutting Motor : 2.2 kw
Feeding Motor : 1.5 kw
Air Consumption : 2 kw
Electric Supply: 415V 3 phase 50Hz.
Overall Machine Weight: 3300 Kg (Approx).
Overall Dimension: 3530 × 1030 × 2110
[mm]

KEY FEATURES:

Can Edit any 2D Shapes with Max. 50 Angles, the data base can store more than 500 shapes.
Different shapes can be processed continuously without stop, furthermore no need to stop the processing while adjusting the bending angle.
Large Storage Capacity can save 500 Processing Geometric Designs, High Degree Automation.
High power feeding Servo Motor’s To Ensure Straightening, Bending & Cutting Accuracy.
